M4 Pro chip in detail: Apple sets new performance standards

The newly announced M4 Pro chip in the Mac mini sets new standards in terms of performance and efficiency. With increased CPU and GPU performance, support for up to 64 GB of RAM and integrated Thunderbolt 5 technology for the first time, the M4 Pro takes the performance of the Mac mini to a new level.

With the M4 Pro chip, Apple is ushering in a new era for the Mac mini. After the M4 chip in the iMac already generated initial positive reactions, the M4 Pro is raising expectations even further. The additional CPU cores, the faster GPU and Thunderbolt 5 support make the Mac mini a serious alternative for anyone who needs maximum computing power.

Technical data of the M4 Pro chip

The M4 Pro chip offers an impressive hardware configuration that was specifically developed for high demands:

CPU performance: The M4 Pro is equipped with 14 CPU cores, including 10 performance cores and 4 efficiency cores. This core combination ensures an optimal balance of speed and energy efficiency. Especially compared to the previous model, the M3 Pro, with its 6 performance and 6 efficiency cores, the M4 Pro shows a significant increase in performance.
GPU performance: The GPU of the M4 Pro chip has up to 20 cores. This makes the new Mac mini suitable for graphics-intensive applications such as video editing, 3D modeling and gaming. Even the base configuration with 16 GPU cores brings a significant increase in performance compared to previous models.
RAM: The Mac mini with M4 Pro chip supports up to 64 GB of RAM. The standard configuration starts at 16 GB, which is already a solid foundation for most professional applications. This high memory capacity ensures that even memory-intensive tasks can be handled smoothly.

Thunderbolt 5 – The fastest connection technology

One of the most groundbreaking innovations in the M4 Pro chip is the integration of Thunderbolt 5. This enables data transfer rates of up to 120 Gbit/s, which is a significant improvement over the previous maximum of 40 Gbit/s of Thunderbolt 4. For anyone who regularly processes large amounts of data or uses external storage solutions, this means a significant time saving.

Exclusive Thunderbolt 5 ports: Thunderbolt 5 ports are only available in Mac mini models with the M4 Pro chip because they require the extra bandwidth of this powerful chip. There are three of these high-speed ports on the back of the device, which significantly speed up data transfer and expand the flexibility of connecting external devices.

memory bandwidth and system performance

Another benefit of the M4 Pro chip is increased memory bandwidth. The chip achieves memory bandwidth of up to 273 GB/s, an improvement of about 80% over the M3 Pro, which was at 150 GB/s. This bandwidth approaches the benchmark of the more powerful M3 Max, making Mac mini an excellent choice for demanding workloads.

System-on-a-chip architecture: The high memory bandwidth of the M4 Pro chip is supported by the system-on-a-chip architecture. This architecture optimizes communication between the components and ensures that there is no loss of performance even in computationally intensive processes.

price-performance ratio

The base model of the Mac mini with M4 Pro chip includes a bundled 12-core CPU and 16-core GPU, but for an additional $250 you get the full power of the chip with 14 CPU and 20 GPU cores. This option is ideal for users who want maximum performance and are willing to invest in the best features.

Desktop performance at a new level: The M4 Pro chip in the Mac mini

The M4 Pro chip in the Mac mini marked a significant advancement in desktop computer technology. With more performance cores, increased GPU capacity and innovative Thunderbolt 5 support, the Mac mini is now more powerful than ever and meets even the highest demands. Whether for creative work, data-intensive applications or professional multitasking environments - the Mac mini with M4 Pro chip is ready to give you the performance you need. (Image: Apple)
